-25 ℃ No Cracks PVC Waterproofing Membrane Polyvinyl Chloride Plastic Sheets 1.5mm/2.0mm

-25 ℃ No Cracks PVC Waterproofing Membrane Polyvinyl Chloride Plastic Sheets 1.5mm/2.0mm

Brand Name: shhous
Model Number: 1.2mm,1.5mm,2.0mm
MOQ: 3000㎡
Price: USD 3.0‑6.15 /㎡
Supply Ability: 500000㎡per Month
Detail Information
Place of Origin:
shandong,china
Certification:
ISO
Low Temperature Bending Property:
-25 ℃ No Cracks
Water Impermeability:
0.3MPa, 2h, Impermeable
Impact Resistance:
0.5 Kg·m, Waterproof
Heat Treatment Dimensional Change Rate / %:
≤0.5
Seam Peel Strength/(N/mm):
≥3.0
Trapezoid Tear Strength/N:
≥250
Maximum Tension/(N/cm):
≥250
Elongation At Maximum Tensile Force /%:
≥15
Packaging Details:
Tape Plastic Bag
Highlight:

no cracks pvc waterproofing membrane

,

pvc waterproofing membrane polyvinyl chloride

,

1.5mm pvc roof membrane

Product Description

Polyvinyl Chloride Plastic Sheets For Waterproofing‌



Product Features

 Roofing-specific PVC waterproofing membrane belongs to the category of exposed type internal reinforcement, taking PVC resin as core raw material, adding high proportion of UV absorbers, antioxidants and light stabilizers, and matching with middle polyester fiber rib structure. Its tensile strength is ≥15MPa, elongation at break ≥280%, artificial climate accelerated aging test can reach8000 hours, far exceeding the basic requirement of national standard 2500 hours. The product's low-temperature bendability can reach -25℃ without, some high-end customized models can achieve low-temperature bending at -40℃ without damage, size stability deviation within6 hours at 80℃ is ≤±2%, and it can maintain stable performance in outdoor environment at -20℃~0℃ for a long time.

performance metric

No. Item Standard Requirement
1 Regular thickness specifications 1.5mm/2.0mm
2 regular width 2.0m
3 ensile Strength / Maximum Tensile Force

≥10.0MPa (Category H) /

 ≥250N/cm (Category P)

4 elongation at break ≥200%
5 low temperature bending property -25℃ no cracks
6 Artificial climate aging ≥2500h
7 core special indicator Wind uplift resistance ≥3.5kPa, ultraviolet reflectance ≥85%
8 implementation standards GB12952-2011

Use & Function

 This type of membrane is a core waterproofing material for roofs of various buildings such as industrial plants, commercial office buildings, villas, schools, etc. It can not only be directly applied to new flat roofs and sloped roofs, but also be suitable for the renovation and waterproofing of steel structure metal roofs. It does not require an additional cement mortar layer, can be directly exposed to outdoor environments, and can long-term resist ultraviolet radiation, drastic temperature changes, rain erosion and hail impact, fundamentally avoiding the that traditional asphalt membranes will age and crack within 3-5 years of exposed use. Meanwhile, the vapor permeability the membrane can timely discharge residual moisture in the roof base layer, preventing the waterproof layer from blistering and delaminating. Combined the integrated seam process of hot air welding, it can form a whole seamless waterproof system, completely solving the common pain points of roof leakage.

-25 ℃ No Cracks PVC Waterproofing Membrane Polyvinyl Chloride Plastic Sheets 1.5mm/2.0mm
